With over 25 years in the Microwave RF industry, Diamond Engineering delivers automated antenna measurement solutions that rival our competitors by suiting even the most complex testing while meeting even the tightest budget requirements.

Antenna Measurement Systems

We specialize in complete ready-to-use antenna measurement systems featuring precision positioners and software for automated measurements of antennas and devices up to 110 GHz.

Calibrated Antennas

Individually calibrated standard and custom antennas for test and measurement applications

RF and Wireless Test Software

Software for both passive and active antenna measurements including OTA pre-compliance tests for LTE and other standards

Complete Turnkey Solutions

Full turn-key solutions which can include everything from shielded chambers to small antenna measurement systems and software, for both passive and active antenna and device measurements.

Antenna Test Services

Full service antenna and device measurements up to 67 GHz

Anechoic Chamber and Shielding Services

Whether building a new chamber, upgrading an old chamber, or improving shielding effectiveness. We have a solution that’s right for you.

THE NEXT BEST THING IN ANTENNA MEASUREMENT

We went above and beyond to create a fantastic measuring experience. Perfectly crafted systems to suite your needs with almost unlimited options to get almost unlimited results.

Quote Request

Recent Library Entries

Using the AZ-EL-F 3D Plot with DE700_26

December 10, 2019
0 comments

In this video, we will utilize the AZ-EL-F 3d plotting module to examine the new Diamond Engineering DE700_26 reference horn. For more information on the additional module, Antenna & Network Simulator, please click below: More Information

DE700_20 Horn Examination

December 10, 2019
0 comments

In this video we examine the characteristics of the Diamond Engineering DE700_26 test horn. For more information on the additional module, Antenna & Network Simulator, please click below: More Information

Available Antenna Gain

December 10, 2019
0 comments

In this video, we will demonstrate how to use your Diamond Engineering tools to examine measured gain parameters and compare them to the total available gain parameters. For more information on the additional module, Antenna & Network Simulator, please …

Making Calibration Files with S1P Files

December 10, 2019
0 comments

In this video, we’ll demonstrate the use of S1P files, including how to import and export them in DAMS Antenna Studio. We also discuss the formatting of and the difference between S1P and S2P files. Additionally, we explain utilization of …

Cable and AUT Mismatch

December 10, 2019
0 comments

In this video, we’re going to demonstrate making measurements with imperfect cables. We’ll also examine how to make measurements with AUT’s that are not perfectly matched. For more information on the additional module, Antenna & Network Simulator, please click …

Using S2P to Match an Antenna

December 10, 2019
0 comments

In this video we will explore using S2P to match an antenna. For more information on the additional module, Antenna & Network Simulator, please click below: More Information

Effective Aperture (Simple Gain Equation) Tutorial

December 10, 2019
0 comments

In this video, we will examine the effective aperture calculation for the DE700_26 horn. We will also introduce a very simple relationship which will enable you to mentally calculate the gain at any frequency. For more information on the …

Purcell Mirror Method

December 10, 2019
0 comments

In this video, we will demonstrate the methodology of antenna measurement using a variation of the Purcell reflection method. To begin with, we’ll go over a little bit of the historical background for its application. Following, we examine the the …
